brief information
- Product Origin:
China
- Name:
ACM
- Models:
AC-51
- The product's name::
Low price 280 kg L shape bracket for electromagnetic lock
- Rebar Plate (LxWxH) ::
180 x 50 x 50 (mm)
- Brand :
ACM
- Dimensions: Magnet (LxWx H) ::
250 x 47 x 28 (mm)
- Ready for Shell :
Anodized aluminum
- Operating Mode ::
90 degrees door
- Application:
Internal open wooden doors, narrow box door, metal door
- Keywords:
L-type bracket, Electric Magnetic Door Lock Bracket
Product Description:
Product Parameter | Description of parameters |
| L: 170x40x29 (mm) Z: 130x38x38 (mm) (180Z L) L: 250x47x28 (mm) Z: 180x50x50 (mm) (280Z L) L: 285x54x31 (mm) Z: 189x57x50 (mm) (350Z L) L: 265x70x45 (mm) Z: 185x70x61 (mm) (500Z L) L: 280x80x51 (mm) Z: 190x70x61 (mm) (750Z L) |
Material | High Strength Aluminum Sandblasted |
Fit | Narrow door |
Opening mode | 90 degree door |
Completed for shell | Anodized aluminum housing |
Weight | 0.4 kg / 0.75 kg / 0.82 kg / 1.3 kg / 1.6 kg |
Material | Special Aluminum Alloy Flashing Silver Sand Blasting |
Suitable for | Internal open wooden door, narrow box door, metal door |
Product access
This is Z & L for 180 kg / 280 kg Magnetic Lock Door
Special aluminum, strong and durable
Special design, suitable for wooden doors and metal doors
Easy to install and convenient to use
It is safe, reliable and efficient
This 180 kg 280 kg Z & L Sty L e Magnetic Lock bracket for access control system L Requires interfacing with magnetic locks for in-swing door applications. Our lock bracket is special aluminum, solid and durable. The bracket ensures that the magnet remains on the protected side of the door, the best choice of access control. Magnetic locks are great for low, medium and high traffic areas such as offices, shops, building entrances and exits.
